Commercial drawings
Planning drawings, building regulations drawings and layouts for shops, offices, units and other commercial premises.
Clear drawings for commercial projects.
We prepare drawings for commercial property owners, tenants, builders and developers, from a single shop to a larger scheme.
Commercial projects tend to have more parties involved: a landlord, a tenant, a contractor, the council and building control. They all need to be looking at the same drawing.
We survey the premises, draw the existing and proposed layouts and prepare whatever the project needs for approval.
What you get
- A measured survey of the premises
- Existing and proposed layouts
- Planning application drawings
- Building regulations drawings
- 3D visuals for clients and landlords
We aim to reply within one working day.
Commercial work we draw.
Shops and shopfronts
New shopfronts, signage zones and internal layouts.
Offices
Fit-out layouts, partitions and escape routes.
Restaurants and takeaways
Layouts, extraction routes and change of use drawings.
Industrial units
Mezzanines, subdivisions and new openings.
Conversions
Commercial buildings converted to flats or other uses.
Licensing and lease plans
Scaled plans for licences, leases and landlords.
One set of drawings everyone can work from.
We keep the drawings clear and consistent, so the landlord, the contractor and building control are all reading the same thing.
- Layouts drawn to scale
- Fire escape and access considered
- Planning and building control submissions
- Revisions turned around quickly
Three steps to approved drawings.
Talk it through
Tell us about the property and what you want to do. We visit or work from what you send us.
We draw it up
We prepare the drawings and send you drafts to check and change.
Submission
We finalise the package and submit it, or hand it to you ready to go.
Do I need planning permission to change a shopfront?
Usually, yes. A new or altered shopfront normally needs planning permission, and signage may need advertisement consent.
Do commercial fit-outs need building regulations approval?
Often. Work affecting structure, fire safety, access or services usually needs approval.
Can you work with our contractor?
Yes. We regularly work alongside builders and shopfitters.
Do you work outside Liverpool?
Yes. We are based in Liverpool and work across the UK.
You might also need.
Let's talk it through.
Tell us about the property and what you want to do. We’ll come back with a fixed quote and the best route to approval.
